Connecting Battery Power Cables
• TO CREATE A LONGER BATTERY POWER CABLE
1
C8
2
2
DANGER!
Pull back to comfirm the connection is secure
4
Ensure that the cable polarities are correct.
4 6 |
• Before disconnecting the battery terminals, you MUST set the BATTERY SWITCH on top of the
Junction Box to OFF position, then press and hold the BATTERY ON/OFF button on the right
side of the junction box for 10 seconds, until the indicator is off.
• Both ends of the positive cable are positive connectors. Both ends of the negative cable are
negative connectors.
C6
1
6-7.5 mm
BAT terminal
C8
2
3
×2
A12
Click
5
1
6-7.5 mm
Click
