System Installation
Installation Environment Requirements
NOT INTENDED FOR MOBILE
SCENARIO
3 2 |
• The installation and operation environment must meet relevant international, national, and
local standards for lithium batteries and the inverter.
• When installing the equipment in a garage, keep it away from the drive way.
• The mounting structure where the equipment is installed must be fire resistant. Do not install the
equipment on flammable building materials. Suitably non-combustible materials are: brick or
masonry block, concrete.
• The material shall have no vents or perforations within the zone required to be covered by the
barrier.
• Install the inverter to a wall that is sufficiently load-bearing (40kg).
• Ensure that the installation surface is solid enough to bear the weight of the equipment.
• Suitable locations for installation may include garages, storage rooms, a dedicated battery system
room and verandas.
• The system shall not be installed:
(a) in restricted locations, as defined for switchboards in AS/NZS 3000;
(b) within 600 mm of any exit;
(c) within 600 mm of any vertical side of a window or building ventilation that ventilates a
habitable room;
(d) within 600 mm of any hot water unit, air conditioning unit or any other appliance not
associated with the pre-assembled integrated BESS;
(e) within 900 mm below any of the items included in Items (b), (c) and (d);
(f) in ceiling spaces;
(g) in wall cavities;
(h) on roofs, except where specifically deemed suitable;
(i) under stairways;
(j) under access walkways;
(k) in an evacuation route or escape route.
AVOID DIRECT SUNLIGHT, RAIN OR SNOW
IP65
AVOID THE
WATER PIPES
AND POWER
CABLES
0%-100%RH
-
20℃-50℃
NOT INTENDED FOR IMPORTANT
DEVICES
DISTANCE FROM
ALTITUDE
THE SEA
Salt
Corrodition
≤3000m
>500m
AWAY FROM CHILD
&WORKING & LIVING AREAS
WELL-
VENTILATED
AREA only
90°
AWAY FROM
Solvents
