Installing Battery
• WITH ADJUSTABLE FEET
1
C2
C6
C2
65-85mm
·WITHOUT ADJUSTABLE FEET
1
C2
65-85mm
C2
3 4 |
• When drilling holes, avoid the water pipes and power cables buried in the wall and under the
floor.
• When drilling holes, protect the battery base from shavings or dust.
• Before installing the battery, make sure that the click-on terminals on the top and bottom of the
battery are free of foreign objects or any liquid.
• Ensure the batteries are mounted on the wall to avoid falling over, tipping, or seismicity.
• Assign enough personnel (two or more) to move battery to avoid personal injury and battery
damage.
• When moving battery, hold handles on top of the battery module.
• Sealant is applied underneath the battery base to ensure its resistance against water.
• There will be a gap between the battery junction box and the battery pack before the screws are
tightened. This gap is caused by the mechanical design to meet the IP rating, and will normalize
after the screws are tightened.
• (Optional) Install the provided adjustable feet to the base if needed. Then you can adjust
the feet and check the level on the base to ensure that the base is placed horizontally, screw the
nuts of the four feet to the top to lock.
2
×1
×4
C5
C4
A9
×1
×1
❶
×1
XX
3
×1
C4
C4
❷
A9
XX
Bohrsc hablone
e
Marking -off templat
C4
