Radiator thermostat II [+M]
Temperature drop
This service uses the temperature measured at the thermostats to
automatically recognise a drop in temperature in the room. In addition
to receiving a message, the room temperature can also be temporarily
reduced to the lowest setting. The radiator thermostat displays Lo.
This service can also be used in addition to the "Sustainable ventilation"
service to generate a message when the room has been sufficiently
ventilated.
Operation in third-party Matter Smart Home system
Requirements
To operate the radiator thermostat II [+M] on a third-party Matter Smart
Home system, a successfully set up Matter controller that supports the
Thread protocol and the associated app from the third-party provider
are required. If the Matter controller does not have integrated thread
communication, a Thread border router will also be required. Please
contact the respective third-party provider for more information.
Matter Smart Home controller and app
Pairing process (coupling)
݅ After inserting the batteries for the first time or after resetting to factory
settings, the status LED (C) of the radiator thermostat II [+M] flashes
blue. The device is ready for coupling to the Matter Smart Home system.
Open the third-party app and add the device there.
݅ Attention! Pairing mode (also referred to as coupling mode) is only
active for 3 minutes after inserting the batteries for the first time. If the
status LED (C) no longer flashes regularly, pairing mode has ended. It
can be activated again by pressing ○ ○ , turning in the direction of +/- or
by removing and inserting a battery. Ensure that the battery polarity is
correct.
