4.2.2. Slatted frame
1. The headrest with transformer
structure (2). The locking bolts
2. Pull the foot-end with its rails from the rear over the rollers of the hinged unit.
3. Push the coupling tubes into each other and secure them on both sides with the fixing
screws.
4. Lay the slats on the guides and gently press them in to position.
4.2.3. Head panel / foot panel
1. Slide the head panel
(3)
fixing screws
2. Firmly tighten both fixing screws.
3. Repeat the steps above for the foot panel.
Installation manual | 2024-12
(1)
should be placed in the black receptacles of the hinged
(3) of the slatted frame are for security.
(2)
into the mattress slatted frame
must first be unscrewed.
(1)
at the head end of the bed. The
