Description of burner
The burners VECTRON G 05.700/1000
DUO PLUS are modulating burners in a
monoblock configuration. Within their
corresponding power range, they are
suitable for use with all heat generators
designed to conform to EN303.
For any other use, the agreement of
ELCO must be asked for.

Important notes

The design and function of this burner
both conform to EN 676 standards.
All installation, initial-startup and
maintenance work must be carried out
by authorised service engineers, who
should observe all relevant guidelines,
directives and specifications.
The installation of the gas conduits and
valve assemblies should likewise be
carried out in conformity with the
applicable directives and regulations
(e.g. DVGW-TRGI 1986/96 ; TRF 1988 ;
DIN 4756).
All seals and sealing material used
must be DVGW (ARGB-KVBG for
Belgium) tested and approved. Check
seals and connection points for
possible leaks with a suitable
non-corrosive foam product.
Bleed the gas conduit before using for
the first time. DO NOT bleed via the
furnace. Servicing work on switches,
limiting devices and control units -
along with other safety devices - MUST
be carried out by the supplier of each
individual item, or by its authorised
service engineers. Original parts may
only be replaced by an authorised
service engineer.
EN 676
Forced-draught gas burner
EN 60335-2
Safety of electrical devices designed for
domestic use
22
Contents. . . . . . . . . . . . . . . . . . . . . . 22
Important notes . . . . . . . . . . . . . . . . . . 22
Technical data, power graphs . . . . . . . . . . 23
Selection of gas valve assembly . . . . . . . . . 24
Burner description . . . . . . . . . . . . . . . . . 25
Dimensions . . . . . . . . . . . . . . . . . . 26-27
Compact valve assembly . . . . . . . . . . . 28-29
TC Control Panel . . . . . . . . . . . . . . . . . 30
Control unit . . . . . . . . . . . . . . . . . . . . 31
Burner assembly . . . . . . . . . . . . . . . . . 32
Assembly of the gas ramp, tightness controller . . 33
Checking / Setting . . . . . . . . . . . . . . . . 34
Burner head for natural gas / Propane gas . . . . 34
Gas supply, electrical supply . . . . . . . . . . . 35
Pre-startup check . . . . . . . . . . . . . . . . . 35
Burner adjustment data . . . . . . . . . . . . . . 36
Airflow control . . . . . . . . . . . . . . . . . 36-37
Burner adjustment . . . . . . . . . . . . . . . . 38
Air pressure / Gas pressure switch setting . . . . 38
Checking for correct functioning. . . . . . . . . . 38
Maintenance . . . . . . . . . . . . . . . . . 39-40
Troubleshooting . . . . . . . . . . . . . . . . . . 41
Gas conduits and valve assemblies
must be installed in accordance with
DVGW-TVR/TRGI (gas).
Place of installation
The burner must not be operated in the
presence of corrosive fumes (e.g.
hairspray, tetrachloroethylene or carbon
tetrachloride), large amounts of dust, or
high levels of air humidity (e.g. in
laundry rooms).
Ensure that a ventilation inlet of the
following characteristics is provided:
DE : up to 50kW: 150cm
for each additional kW: + 2,0cm
CH : up to 33kW : 200 cm²
for each additional kW: + 6,0cm
Rules may vary according to local
legislation.
Scope of delivery
The burner assembly is supplied in
three separate packages:
burner with operating instructions,
-
flow diagram, spare parts list,
boiler-room information sheet, burner
head, flange gasket and fixing
screws,
combustion head with flanged joint
-
and fastening screw
gas-valve assembly.
-
Accessories available at request
leak controller VPS 504
-
manometer
-
compensator
-
test burner
-
air intake caisson
-
sound insulation caisson
-
hour meter
-
universal controller RWF 40
-
potentiometer on servomotor
-
testable pressure switch
-
display
-
remote reset
-
03/2005 - Art. Nr. 13 018 104A
Page
Declaration of conformity for
forced-draught gas burners
We, CEB,
F-74106 ANNEMASSE Cedex
declare under our sole responsibility
that the products
VECTRON G 05.700 DUO PLUS
VECTRON G 05.1000 DUO PLUS
conform to the following standards:
EN 60335
EN 50081
EN 50082
EN 676
In accordance with the stipulations of
directives
89 / 396/EEC gas devices
89 / 336/EEC EMC directive
73 / 23 /EEC low-voltage devices
92 / 42 /EEC working efficiency
97 / 23 /EEC pressure equipment
These products bear the CE marking.
Annemasse, January 1st 2004
J.HAEP
We can accept no warranty liability
2
whatsoever for loss, damage or
2
injury caused by any of the
following:
2
.
unauthorised use - Incorrect
-
installation and/or
initial startup on the part of the
-
buyer or any third party, including
the fitting of non-original parts.
startup of the installation with high
-
pressure
Handover and operating
instructions
The person engaged to install the firing
system must provide the user with
operation and maintenance instructions
no later than at the moment in which
the unit is handed over for use. These
instructions should be displayed in a
prominent location at the point of
installation of the heating unit, and
should include the address and
telephone number of the nearest
customer service centre.
Advice to the user
Have the system professionally
serviced at least once a year. It is rec-
ommended to enter into a maintenance
contract in order to ensure trouble-free
running.
directive
directive
directive
