NOTE
This product is equipped with a Röhm drill
u
chuck with an anti-lock function .
If you attempt to open the fully opened
u
chuck further, the anti-lock function will
[ 1 ]
be activated to protect the chuck .
When the anti-lock function is activated,
u
the chuck cannot be closed by turning
[ 1 ]
the chuck ring
2 ] [
A ratcheting sound will be produced when
you attempt to close the chuck .
Deactivating the chuck's
u
function: Turn the chuck ring
clockwise direction by a certain extent .
Then, turn the chuck ring
quickly in a counter-clockwise direction .
Repeat this action if the anti-lock function
is still active . When the anti-lock function is
deactivated, you should be able to close
the chuck without ratcheting sounds .
[ 1 ]
˜ Trial run
NOTE
Always carry out a no-load trial run before
u
starting work and after every accessory
tool replacement . Switch the product off
immediately if the accessory tool is not
running smoothly, if considerable vibration
occurs or if you hear abnormal noises .
Before operating the product, check whether
o
the accessory tool is correctly positioned, i .e .
centred in the chuck
Screw bits are labelled according to their
o
dimensions and their shape . If you are
uncertain, always check whether the bit fits
tightly in the screw head without any free
play .
in a clockwise direction .
anti-lock
1 ] [
in a
2 ] [
suddenly and
2 ] [
.
1 ] [
˜ Operation
˜ Gear selection
m ATTENTION! Risk of product
damage!
Do not operate the gear selector
until the product has come to a
standstill .
Change the gear by sliding the gear
o
selector forwards or backwards (fig . F) .
[ 4 ]
1 gear:
st
Suitable for:
Speed:
Torque:
2 gear:
nd
Suitable for:
Speed:
Torque:
˜ Setting the rotating direction
m ATTENTION! Risk of product
damage!
Do not operate the rotation direction
switch until the product has come to
5 ] [
a standstill .
Change the direction of rotation by pressing
o
the rotation direction switch
left or right (fig . G) .
When the rotation direction switch
o
the middle position, the on/off switch
locked .
˜ Torque control
This product is equipped with a torque control that
disengages the spindle when a predefined torque
is exceeded .
The torque can be adjusted by turning the
o
torque sleeve (fig . H) .
[ 3 ]
Small screws or soft materials: Select a low
o
level .
4 ] [
Screwing
Low
High
Drilling
High
Low
towards the
5 ] [
is in
5 ] [
is
6 ] [
