Start-up
actuator and afterwards the pair-
ing mode of the Multi IO Box.
If you want to pair the Muli IO Box with
a Homematic IP Floor Heating Actua-
tor, the pairing mode of both devices
has to be activated first. To do this,
proceed as follows:
• Press and hold down the system
button (A) of the Multi IO Box for
at least 4 seconds to activate the
pairing mode. The device LED
flashes orange.
Figure 12
• Activate the pairing mode of your
floor heating actuator. Briefly press
the select button until the LEDs of
all channels light up green.
• Press and hold the system button
on the floor heating actuator for
4 seconds until the LED starts to
flash orange fast.
Figure 13
The device LED (A) flashes green to
indicate that pairing has been success-
ful. If pairing failed, the device LED (A)
lights up red. Please try again.
If no pairing operations are per-
formed, pairing mode is exited
automatically after 3 minutes.
7.4.2 Pairing with the Homematic IP
Access Point
You can connect the device either
to the Homematic IP Access Point
or the Central Control Unit CCU3.
Further information is available in
the Homematic IP User Guide
(available to download in the
Downloads section at
www.homematic-ip.com).
First set up your Homematic IP
Access Point using the
Homematic IP app so that you can
use other Homematic IP devices
in the system. For further informa-
tion, please refer to the Ac-
cess Point operating manual.
To add the Multi IO Box to the Access
Point, please proceed as follows:
• Open the Homematic IP app on
your smartphone.
• Select "Add device".
• Briefly press the system button (A)
until the LED starts to flash orange
slowly (see
mode is active for 3 minutes.
You can manually start the pairing
mode for another 3 minutes by
briefly pressing the system button
(A) (see figure).
figure). The pairing
27
