3.2. Specifications P 3285
Range
Accuracy
Voltage
Internal Residual Capacitance
Operating Temperature
Weight
Dimensions (WxHxD)
Accessories
3.2.1. Front Panel Description
3-1 Range Select Switch
3-2 Capacitance Output Terminal
3.2.2. Testing Procedure
1. Start with all switches up (0) for min. capacitance.
2. Switch down (1) to add Capacitance value.
WARNING!!
Do not add the voltage more than 50 V DC to the "Output Capacitor Terminals" (3-2)
100 pF to 11,111 µF (100 pF per step)
5 % capacitors used throughout
< 1 µF, 1 kHz test frequency
> 1 µF, 100 Hz test frequency
50 V DC, non-polarized capacitors
50 pF max.
0° C to 50° C (32° F to 122° F) < 80% RH
350 g.
140 x 190 x 80 mm
Operation Manual
3-1
3-2
-10-
