3. Specifications
3.1. Specifications P 3280
Range
Accuracy
Wattage
Max. Input Voltage
Internal Stray Resistance
Operating Temperature
Weight
Dimensions (WxHxD)
Accessories
3.1.1. Front Panel Description
3-1 Range Select Switch
3-2 Resistance Output Terminal
3.1.2. Testing Procedure
1. Start with all switches up (0) for 0 ohms.
2. Switch down (1) to add Resistance value.
WARNING!!
*
The Wattage of the "Output Resistor" is 0,3 W. Do not add the Wattage more than 0,3 W to the
"Resistance Output Terminals" (3-2)
*
Do not add the voltage over AC/DC 250 V to the "Output Resistance Terminals" even its stand
Wattage is less than 0,3 W.
1 to 11.111.110 Ohm (1 Ohm per step)
1 % resistors used throughout
2 W
250 V AC/DC
Max. 0,3 Ohm
0° C to 50° C (32° F to 122° F) < 80 % RH
400 g
140 x 190 x 80 mm
Operation Manual
3-1
3-2
-9-
