1. Sicherheitshinweise zum Betrieb des Gerätes Dieses Gerät erfüllt die EU-Bestimmungen 2004/108/EG (elektromagnetische Kompatibilität) und 2006/95/EG (Niederspannung) entsprechend der Festlegung im Nachtrag 2004/22/EG (CE- Zeichen); Verschmutzungsgrad 2. Zur Betriebssicherheit des Gerätes und zur Vermeidung von schweren Verletzungen durch Strom- oder Spannungsüberschläge bzw. Kurzschlüsse sind nachfolgend aufgeführte Sicherheitshinweise zum Betrieb des Gerätes unbedingt zu beachten.
Seite 3
Bereich (1 Ohm bis 11,111 MOhm) mit hoher Auflösung (1 Ohm pro Schritt), praktisches und vielseitiges Werkzeug Mit 7 Widerstands-Dekaden ® PeakTech 3285 breiter Bereich (100pF bis 11,111 µF) mit hoher Auflösung (100 pF pro Schritt), praktisches und vielseitiges Werkzeug Mit 5 Kapazitäts-Dekaden ® PeakTech 3290 breiter Bereich (10 µH bis 111,1 mH) mit hoher Auflösung (10 µH pro Schritt), praktisches und...
3. Spezifikationen 3.1. Spezifikationen P 3280 Bereich 1 Ohm bis 11.111.110 Ohm (1 Ohm pro Schritt) Genauigkeit 1% Widerstandstoleranz in allen Bereichen Leistung Max. Eingangsspannung 250V AC/DC Interner Streuwiderstand max. 0,3 Ohm Betriebstemperatur 0° C bis 50° C (32° F bis 122° F) <80%RH Gewicht 400 g Abmessungen (BxHxT)
Seite 5
3.2. Spezifikationen P 3285 Bereich 100 pF bis 11,11 1µF (100 pF pro Schritt) Genauigkeit 5% Kapazitäts-Toleranz in allen Bereichen < 1µF, bei 1kHz Testfrequenz > 1µF, bei 100Hz Testfrequenz Max. Eingangsspannung 50V DC, nicht polarisierte Kapazitäten Interne Restkapazität max. 50pF Betriebstemperatur 0°...
Seite 6
3.3. Spezifikationen P 3290 Bereich 10µH bis 111,1mH (10uH pro Schritt) Genauigkeit 5% Induktivitäts-Toleranz in allen Bereichen bei 23° C +/-5° C bei 1kHz Testfrequenz Max. Eingangsstrom 100 mA AC oder DC Interne Restinduktivität ca. 0,6 µH Betriebstemperatur 0° C bis 50° C (32° F bis 122° F) <80%RH Gewicht 450 g Abmessungen (BxHxT)
1. Safety Precautions This product complies with the requirements of the following European Community Directives: 2004/108/EC (Electromagnetic Compatibility) and 2006/95/EC (Low Voltage) as amended by 2004/22/EC (CE-Marking); pollution degree 2. To ensure safe operation of the equipment and eliminate the danger of serious injury due to short- circuits (arcing), the following safety precautions must be observed.
Seite 9
1 to 11,111 MOhm wide range and high resolution (1 Ohm per step), practical and versatile tools With seven decades of resistance ® PeakTech 3285 100 pF to 11,111 µF, wide range and high resolution (100 pF per step), practical and versatile tools With five decades of capacitance ®...
3. Specifications 3.1. Specifications P 3280 Range 1 to 11.111.110 Ohm (1 Ohm per step) Accuracy 1 % resistors used throughout Wattage Max. Input Voltage 250 V AC/DC Internal Stray Resistance Max. 0,3 Ohm Operating Temperature 0° C to 50° C (32° F to 122° F) < 80 % RH Weight 400 g Dimensions (WxHxD)
Seite 11
3.2. Specifications P 3285 Range 100 pF to 11,111 µF (100 pF per step) Accuracy 5 % capacitors used throughout < 1 µF, 1 kHz test frequency > 1 µF, 100 Hz test frequency Voltage 50 V DC, non-polarized capacitors Internal Residual Capacitance 50 pF max.
Seite 12
3.3. Specifications P 3290 Range 10 µH to 111,1 mH (10 µH per step) Accuracy 5 % inductors used throughout at 23° C +/- 5° C at 1 kHz test frequency Max. Rating Current 100 mA DC or AC Internal Residual Inductance Approx.
