Error Possible cause
LED UL/UA flashes green The supply voltage is less
than the lower tolerance limit
(18 V DC) and more than
10 V DC
LED UL/UA illuminates red The valve supply voltage is
less than 21.6 V DC
LED UL/UA is off The supply voltage is less
than 10 V DC
LED UL/UA flashes red The supply voltage is greater
than 26.4 V DC
LED DIAG flashes red No module connected to the
product
Diagnostic message for open
load/short circuit at valve
available.
LED DIAG illuminates red Diagnostic message available. Check module.
Internal connection error or
hardware error.
Product is not detected.
NS LED illuminates red Serious network error
NS LED flashes red Connection to master has
been disconnected. No com-
munication via Ethernet/IP
possible.
Error in the PLC configuration. Check PLC configuration.
LED L/A 1 or LED L/A 2 illumi- No data exchange with the
nates green and flashes yel- bus coupler.
low
Bus coupler has not been con-
figured in the control.
LED L/A 1 or LED L/A 2 is off No connection to network
participant.
Connecting cable damaged.
Network participant dam-
aged.
Product damaged.
14 Technical data
This section contains an excerpt of the most important technical data. Further
technical data can be found on the product page in the Emerson store.
General
Dimensions
Weight
Material
Degree of contamination
Relative humidity
Ambient temperature for storage
min. ... max.
Ambient temperature during operation
min. ... max.
Max. number of valves
Max. height above sea level
Vibration resistance for EN 60068-2-6
wall mounting
Shock resistance for EN 60068-2-27 wall
mounting
Electrics
Degree of protection according to
EN 60529 / IEC 60529
Supply voltage
Valve supply voltage
Nominal current
Power supply connection type
Current consumption of the electron-
ics
AVENTICS™ Ethernet/IP | 570090-BAL-AB | English
Remedy
Check power supply on plug
connector X1S.
Connect the module.
Check the connection of the
valves.
Contact manufacturer
Check network settings
Check the connection to the
master.
Connect network section with
the control.
Bus coupler configured in the
control.
Connect fieldbus connection
X7E1 or X7E2 to network par-
ticipant.
Replace connecting cable.
Replace network participant.
Replace product.
Specifications
45 mm x 97.2 mm x 27.25 mm
0.089 kg
Fiberglass reinforced polyamide
2
95 %, non-condensing
-25 ... 80 °C
-10 ... 50 °C
24 (48 coils)
2000 m
±0.35 mm displacement at 10 Hz ... 60 Hz,
5 g acceleration at 60 Hz ... 150 Hz
30 g with 18 ms duration,
3 shocks each direction
Specifications
IP65 when assembled
24 V DC ±25 %
24 V DC ±10 %
3 A
M12 A-coded, 4 pin or 5 pin
0.2 A
Permissible ripple
Standards and directives complied with
Standard / directive Description
EMC directive Electromagnetic compatibility of electric products and electronic
2014/30/EU products
EN 60204-1 Safety of machinery – Electrical equipment of machines, Part 1: Gen-
eral requirements
EN 61000-6-2 Electromagnetic compatibility (EMC); part 6-2: Generic standards –
interference immunity for industrial environments
EN 61000-6-3 Electromagnetic compatibility (EMC); part 6-3: Generic standards –
Emission standard for equipment in residential environments
Communication interface
Communications protocol
Connections
Ethernet/IP
Max. output data volume
Max. input data volume
15 Spare parts
Information on spare parts can be found on the product page in the Emerson
store.
16 Accessories
Information on accessories can be found on the product page in the Emerson
store.
Description
Plug connector, CN2 series, male, M12x1, 4-pin, D-
coded, 180° straight cable outlet, for the fieldbus con-
nection X7E1/X7E2
• Max. wire cross-section: 0.14 mm² (AWG26)
• Ambient temperature: -25 °C ... 85 °C
• Nominal voltage: 48 V
Base, CN2 series, female, M12x1, 4-pin, A-coded, 180°
straight cable outlet, for the connection of the power
supply X1S
• Max. wire cross-section: 0.75 mm² (AWG19)
• Ambient temperature: -25 °C ... 90 °C
• Nominal voltage: 48 V
Base, CN2 series, female, M12x1, 4-pin, A-coded, 90°
angled cable outlet, for the connection of the power
supply X1S
• Max. wire cross-section: 0.75 mm² (AWG19)
• Ambient temperature: -25 °C ... 90 °C
• Nominal voltage: 48 V
Protective cap M12x1
Specifications
5 %
Specifications
Ethernet/IP
Fieldbus connection X7E1 and X7E2
• Base, female, M12, 4-pin, D-coded
• 100 Mbit full duplex switch with 2 connections,
for connecting several Ethernet/IP devices in se-
ries
Device Level Ring (DLR), Quick Connect
48 bits
112 bits
Item no.
R419801401
8941054324
8941054424
1823312001
