Value of the 4th
SW2 positions
octet
1
2
IP address assign-
1
1
ment via website
7.1.4 Configuring the product manually
1. Ensure that the product is not connected to the control.
2. Set at SW2 255. See
g 7.1.3 Assigning IP address and subnet
3. Call up the IP address of the product in a browser.
4. Select Node Configuration tab.
5. Set the IP address.
6. Set the subnet mask.
7. Set the gateway IP address.
8. Optional: Select the setting Quick Connect.
9. Select Update Configuration.
10.Enter password. See Name plate.
ð Product restarts.
11.If the product does not restart automatically: Separate and reconnect the
power supply.
Reading out diagnosis data
5
4
Fig. 4: Valve driver diagnosis
1 Status: Green=ok, yellow=warning,
red=connection loss
3 Status of the valve coils
5 Bus coupler
5
4
3
2
Fig. 5: Bus coupler diagnosis
1 Button for restoring factory settings
3 Diagnostic data of bit 0
5 Bus coupler
1. Select Diagnostic tab
2. Select Show Details.
Activating valves
1. Check the checkbox.
2. Enter password. See Name plate.
AVENTICS™ Ethernet/IP | 570090-BAL-AB | English
3
4
5
6
1
1
1
1
mask.
2 Checkboxes for activating the valve
coils
4 Valve driver
2 Diagnostic data of bit 1
4 Diagnostic data of the bus coupler
3. Read warning.
4. Confirm warning.
7
8
5. Monitor the valve status.
1
1
Deactivating valves
Uncheck the checkbox.
u
7.1.5 Updating firmware
1. Ensure that the product is not connected to the control.
2. Call up the IP address of the product in a browser.
3. Select Firmware Update tab.
4. Confirm selection.
5. Enter password.
6. Select Choose a Firmware File to upload. See
7. Select file.
ð Firmware upload is displayed as successful in the Event Log.
8. Select Reset.
ð Restart is displayed as successful in the Event Log.
7.2 Step-by-step commissioning
7.2.1 Carrying out a self-test
1. Ensure that the product is not connected to the control.
2. Call up the IP address of the product in a browser.
1
3. Ensure that the pneumatic supply is disconnected.
4. Ensure that all valves are switched off.
2
5. Select Self Test tab.
6. Select Start Self Test.
3
7. Enter password. See Name plate.
ð The valve coils are switched on one after the other for 500 ms.
8. Stop self test: Select Stop Self Test or switch to another tab on the website.
7.2.2 Switching on the product
1. Switch on supply voltage.
2. Check LED displays on all modules.
ð UL and DIAG illuminate green, MS and NS are off, L/A1 or L/A2 flashes yellow.
3. Switch on pressure supply.
1
8 Operation
The device is operated through the system. Observe the information in the sys-
tem documentation.
8.1 Basic requirements
General requirements
• Never switch off, modify or bypass safety devices.
• Do not make any changes to the configuration and hardware during opera-
tion.
• Do not touch the product or any connected parts during operation.
In case of malfunctions during operation
• In case of a malfunction that presents an immediate danger for employees or
systems: Switch off product.
• Carry out analysis and troubleshooting of malfunctions. See
bleshooting.
g 6.2.3 Software
installation.
g 13. Trou-
19
