Auswahl von Leitungen und Sicherungen
C-Leistung (400 V)
Q (kvar)
0,5
1
1,5
2
2,5
3
4
5
6
7,5
10
12,5
15
16,7
20
25
30
33,3
35
40
45
50
60
70
75
80
90
100
120
125
150
180
200
250
300
350
400
450
500
44
Stromaufnahme
je Phase I (A)
0,72
1,44
2,16
2,88
3,60
4,32
5,76
7,20
8,64
10,80
14,40
18,00
21,60
24,00
28,80
36,00
43,20
48,00
50,40
57,60
64,80
72,00
86,40
100,80
108,00
115,10
129,60
144,00
172,80
180,00
216,00
259,20
288,00
360,00
432,00
504,00
576,00
648,00
720,00
Zuleitung
Cu (mm²)
4 x
1,5
4 x
1,5
4 x
1,5
4 x
1,5
4 x
1,5
4 x
1,5
4 x
1,5
4 x
2,5
4 x
2,5
4 x
2,5
4 x
2,5
4 x
6
4 x 10
4 x 10
4 x 10
4 x 16
4 x 16
4 x 16
4 x 25
4 x 25
3 x 35/ 16
3 x 50/ 25
3 x 50/ 25
3 x 70/ 35
3 x 70/ 35
3 x 95/ 50
3 x 95/ 50
3 x 95/ 50
3 x 120/ 70
3 x 120/ 70
3 x 150/ 70
3 x 240/120
3 x 240/120
2 x 3 x 150/ 70
2 x 3 x 185/ 95
2 x 3 x 240/120
2 x 3 x 240/120
4 x 3 x 120/ 70
4 x 3 x 150/ 70
Technische Daten
Absicherung
träge 3 x I (A)
10
10
10
10
10
10
10
16
16
16
25
35
35
35
50
63
80
80
80
100
100
125
125
160
160
200
200
250
250
250
315
400
400
500
630
2 x 400
2 x 400
2 x 500
2 x 500
