en
Outflow Tubing with
Intermediary Tube With One-Way Valve – REF. 284649
Intermediary Tube Without One-Way Valve – REF. 284610
Some products may not be licensed in all jurisdictions.
DESCRIPTION
The Outflow Tubing provides suction from the operative site during arthroscopic
procedures. The Polyvinyl Chloride (PVC) outflow tube is packaged with
an intermediary tube with a one-way valve, or an intermediary tube without
a one-way valve. The Intermediary tubing connects to the Inflow tubing to
deliver irrigation fluid from the irrigation pump to the operative site during
arthroscopic procedures.
To Suction
Cannula
Intermediary
Tubing
or
INTENDED USE
The FMS Outflow Tubing is intended for use with the FMS Fluid
®
Management Systems in a surgical setting by personnel trained in
arthroscopy.
INDICATIONS FOR USE
The Outflow Tubing and Intermediary Tubing are accessories to the FMS
Fluid Management Systems.
To Shaver
FLOW
Auto-lock Device
(Orange)
To Waste
1
Figure 1.
Outflow Tubing
