Adjustment with Robacta W/V or Robacta G/V test-
ing devices
General remarks
The Robacta W/V and Robacta G/V testing devices are designed in such a way that they
can also be used to adjust customer-specific welding torches.
Preparing the
testing device
Detaching the testing unit and torch body bend holder
from the base plate (e.g. Robacta G/V testing device)
Fitting the torch
body bend holder
2.
(4)
2.
(5)
3.
(6)
2.
Remove the testing unit from the base
1
plate
Loosen clamp, detach torch body bend
2
holder from the base plate
Turn the base plate through 180°
3
1.
(1)
Testing unit
(4)
Torch body holder
(5)
Base plate
(6)
Holes
(1)
Position torch body bend holder over
1
the four holes below the adjustable hol-
ders/centring sleeves
Insert screws (supplied with testing de-
2
vice) from below into the holes in the
base plate
Fix torch body bend holder to the base
3
plate
33
