Balanced Body Allegro 2 Bedienungsanleitung Seite 21

B. STANDING THE ALLEGRO 2 WITH THE WHEEL KITS
Number
3 vertical
position
Locking pin
engaged
Figure I
With wheels you can store the
Allegro 2 by standing it on its
foot-end (Figure J).
IMPORTANT SAFETY TIP:
Before standing make sure
the footbar is in the correct
position (number 3 vertical
position, and number 1
horizontal position) and both
locking pins are engaged as
shown in Figure I. You can not
stand the Allegro 2 without
wheels or if you have a Tower
installed.
SECURITY STRAP
For additional safety, Balanced Body offers a Vertical Storage
Strap (part# 10017), which fastens the Allegro 2 (without Tower)
to a wall when in standing position with wheels.
Number 1
horizontal
position
Figure J
VI. FOURTH-SIDE FOR TOWER PUSH-THRU BAR (PTB)
A fourth side for the PTB
(part# 12845) can be ordered
separately. To install, take the
PTB off the frame by removing
the T-pins. Insert and tighten
the included screws into the
holes as shown in Figure K.
Repeat on the other side then
re-attach the PTB to the frame
using the T-pins.
VII. MAT CONVERSION
To install the mat (part# 12313) on the frame disengage the
springs and move the carriage all the way to the head end of the
Reformer. Place the mat (upholstered side up) into the frame and
slide the wooden tongue of the mat under the standing platform
on the foot-end of the frame.
QUESTIONS?
Call Balanced Body Technical Support at
1-800-PILATES or +1-916-388-2838 or info@pilates.com.
Figure K
21
