14 Maintenance and cleaning
WARNING
Pull out the mains plug before carrying out
any setting, servicing or repair work!
14.1 General maintenance tasks
• Clean the product at regular intervals using a damp
cloth and a little soft soap. Do not use any cleaning
products or solvents; they could attack the plastic
parts of the product. Make sure that no water can pen-
etrate the product interior.
• Oil all moving parts once a month.
14.2 Re-tensioning and changing the
toothed belt (Fig. 27, 28)
Tool required:
* = not included in the scope of delivery!
• Phillips screwdriver*
14.2.1 Re-tensioning the toothed belt
1. Remove the belt cover (12) by loosening the screw
with a Phillips screwdriver.
2. Loosen the three fastening screws (12a) with a Phil-
lips screwdriver.
3. To tension the toothed belt, slide the belt housing up-
wards and hold this position.
4. Tighten the fastening screws (12a) firmly.
5. Now check the belt tension and re-tighten it if neces-
sary.
6. Insert the belt cover (12) and firmly tighten it.
14.2.2 Changing the toothed belt
1. Remove the belt cover (12) by loosening the screw
with a Phillips screwdriver.
2. Loosen the three fastening screws (12a) with a Phil-
lips screwdriver.
3. Remove the old belt.
4. Put on the new belt.
5. To tighten the toothed belt, proceed as described in
the chapter Re-tensioning the toothed belt.
14.3 Cleaning
• Keep protective devices, air vents and the motor
housing as free of dust and dirt as possible. Rub the
product clean with a clean cloth or blow it off with
compressed air at low pressure. We recommend that
you clean the product directly after every use.
15 Storage
Store the product and its accessories in a dark, dry and
frost-free place that is inaccessible to children.
The optimum storage temperature is between 5°C and
30˚C.
Store the product in its original packaging.
Cover the product to protect it from dust or moisture.
Store the operating manual with the product.
16 Repair & ordering spare parts
After repairs or maintenance, make sure that all safety-re-
lated parts are installed and are in perfect condition. All
parts which may cause injury must be kept where they
are inaccessible to children or others.
ATTENTION
According to the German Product Liability Act, no liabili-
ty is accepted for damage caused by improper repairs
or by not using original spare parts.
Such work should be performed by a customer service
centre or an authorised specialists. The same applies to
accessory parts.
Connections and repairs
Connections and repair work on the electrical equipment
may only be carried out by electricians.
16.1 Ordering spare parts
Please provide the following information when ordering
spare parts:
• Model designation
• Item number
• Type plate data
Spare parts / accessories
Sanding belt L 915 x W 100 mm, 3 each:
K 240 - Item number:
K 120 - Item number:
K 180 - Item number:
K 80 - Item number:
Sanding paper Ø 150 mm, 10 units
respectively:
K 80 - Item number:
K 120 - Item number:
K 180 - Item number:
K 240 - Item number:
Sharpening set 12 pieces, consisting of:
3 x sanding paper grain size 80/120/180
respectively
1 x sanding belt grain size 80/120/180
respectively
− Article number:
Toothed belt - Item number:
16.2 Service information
With this product, it is necessary to note that the following
parts are subject to natural or usage-related wear, or that
the following parts are required as consumables.
Wearing parts*: Abrasives, toothed belts
* = not included in the scope of delivery!
17 Disposal and recycling
Notes for packaging
www.scheppach.com
7903306602
88000212
88000221
88000211
88000208
88000209
88000220
7903306601
7903302601
88000543
The packaging materials are recy-
clable. Please dispose of packag-
ing in an environmentally friendly
manner.
