• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
WARNING
The product and the packaging material are not
children's toys!
Do not let children play with plastic bags, films or
small parts! There is a danger of choking or suffo-
cating!
8 Assembly
8.1 Installing the sanding table (Fig.
3-6)
1. Fit the sanding table (6) and secure it with the locking
screw (7) and the washer (7a) (Fig. 3+4).
2. Secure the grinding table (6) on the opposite side with
the clamping screw (23) and the washer (24) (Fig.
5+6).
8.2 Inserting the transverse stop (5)
(Fig. 4)
1. Slide the transverse stop (5) into the groove of the
sanding table (6).
2. Turn the transverse stop (5) until the desired angle
has been set (Fig. 21, 22).
8.3 Fitting the stop (Fig. 1, 7)
1. Secure the stop (14) with the Allen screws (15) and
the washers (15a). Use the Allen key (27) for this.
2. Attention! It must be possible for the grinding belt
(13) to run freely.
8.4 Moving the sanding position of the
grinding belt (Fig. 8-10)
1. Use the Allen key (27) to loosen the Allen screw (11).
2. Move the grinding belt (13) upwards into the desired
position.
3. Tighten the Allen screw (11) to fix this position.
4. The sanding table (6) can be inserted in this position
to support the workpiece. To do this, loosen the two
Allen screws (15) and remove the stop (14).
5. Slide the sanding table (6) into the hole of the holder
tube (20) and fix it with the locking screw for sanding
table (7).
8.5 Use as a stationary machine (Fig.
1, 11)
If your machine is to be used in a permanent location, it is
recommended you secure it to a workbench.
1. Mark the drill holes.
– Place the product as it will be installed later.
22 | GB
– Mark the positions of the holes to be drilled on the
workbench.
These are given by the fixing holes (10) in the
base plate (9).
We recommend installing close to the edge to en-
sure that the grinding table (6) can reach the 45°
position.
2. Drill the holes (at least 9 mm diameter) through the
workbench.
3. Place the product over the drilled holes congruent with
the fixing holes (10) in the base plate (9) and insert
the screws (M8*) (25) through the holes from above.
4. Screw the nuts (26) from below onto the screws
(M8x60*) (25).
5. Tighten the nuts (26) using two open-end spanners
AF13*.
* = not included in the scope of delivery!
8.6 Use as a mobile machine
If your product is to be used as a portable tool, it is rec-
ommended you fasten it to a suitable mounting plate.
The mounting plate should be at least 19 mm thick and
sufficiently larger than the product to allow space for the
screw clamps.
Fix the product to the base plate using suitable wooden
screws. The base plate can be clamped to the workbench
with screw clamps (not included in scope of delivery).
9 Before commissioning
9.1 General information
WARNING
Always remove the mains plug before carrying out
adjustments on the product.
• Before connecting of the product, make certain that
the data on the type plate matches with the mains
power data.
• Prior to commissioning, all covers and safety devices
must be mounted correctly.
• It must be possible for the sanding belt and sanding
wheel to run freely.
• In case of previously machined wood, be aware of any
foreign objects, such as nails or screws, etc.
• Before pressing the on/off switch, make sure whether
the sanding paper is correctly fitted, and that moving
parts run smoothly.
10 Commissioning
10.1 ON/OFF switch (4a) (Fig. 12)
1. Press the "I" switch to switch on the product.
2. Press the "0" switch to switch off the product.
10.2 Adjusting the sanding table (Fig. 1,
13, 19, 20)
The sanding table (6) can be infinitely adjusted from 0° to
45°.
The adjustable transverse stop (5) ensures safe guidance
of the workpiece.
