Attention! It must be possible for the sanding wheel (3)
to run freely. The distance between the sanding table (6)
and the sanding wheel (3) should be max. 2 mm.
To set the gap between the sanding table (6) and the
sanding wheel (3), proceed as follows (Fig. 19, 20):
1. Release the clamping screw (23).
2. Loosen the three nuts (16), under the sanding table
(6). Use a hexagon spanner AF10 for this (not includ-
ed in the scope of delivery).
3. Now clamp a panel or similar with a thickness of max.
2 mm between the sanding table (6) and the sanding
wheel (3).
4. Tighten the nuts (16) and the clamping screw (23).
5. Then remove the panel.
10.3 Setting the speed (Fig. 1+12)
With the speed control (4b) it is possible to set the speed
of the grinding wheel (3) and the speed of the grinding
belt (13).
Notes:
The speed can also be changed during operation.
The speed that makes sense when working depends on
what tasks you are doing with the product.
We recommend determining the speed using practical
tests.
The speed of the product can be read on the display.
10.4 Sanding
• Always hold the workpiece firmly during sanding.
• Do not apply excessive pressure.
• The workpiece should be moved back and forth on the
sanding belt or the sanding wheel when sanding. This
prevents the sanding paper from becoming worn on
one side.
ATTENTION
Pieces of wood should always be sanded with the grain
to prevent them splitting.
ATTENTION
If the sanding wheel or the sanding belt jam while you
are working, remove your workpiece. Then wait until the
product has reached its maximum speed again before
you continue working.
10.5 Connecting the extraction port set
(8) (Fig. 1)
The product is equipped with an extraction port.
Connect a dust extractor when processing dusty materi-
als.
10.6 Replacing the sanding paper on
the sanding disc (Fig. 1, 14)
1. Pull out the mains plug.
2. Remove the clamping screw (23) and the metal plate
(24).
3. Unscrew the locking screw for the sanding table (7)
with the washer (7a) and remove the sanding table
(6).
4. Disassemble the disc guard (21) by removing the two
screws (22) with a Phillips screwdriver (not included in
the scope of delivery).
5. Pull the sandpaper (3a) off the sanding wheel (3) and
attach the new sandpaper (3a) (quick-fit fastening sys-
tem) in reverse order.
6. Attach the disc guard (21) again.
7. Fit the sanding table as described under 8.1).
10.7 Replacing the grinding belt (1, 8,
15-18)
1. Pull out the mains plug.
2. Loosen the Allen screw (11) with the Allen key (27).
3. Loosen the screws (17) with a Phillips screwdriver
(not included in the scope of delivery).
4. Take the grinding belt guard (18) off the grinding belt
holder (19). To do this, set the grinding belt holder
(19) at a slight angle.
5. Pull out the grinding belt tensioner (2) to release the
tension on the grinding belt (13).
6. Remove the grinding belt (13) forwards.
7. Mount the new grinding belt in reverse order.
ATTENTION
Note the running direction on the housing and on the in-
side of the sanding belt!
10.8 Adjusting the sanding belt (Fig. 1)
1. Pull out the mains plug.
2. Push the grinding belt (13) by hand slowly in the run-
ning direction.
3. The grinding belt (13) must run centrally on the sand-
ing surface. If not, you can use the knurled screw (1)
to make adjustments.
11 Working instructions
WARNING
Pay attention to your fingers!
Hold the workpiece firmly.
ATTENTION
Care should be taken when sanding particularly thin or
long workpieces.
11.1 Sanding chamfers and edges
(Fig. 1, 19, 20)
The sanding table (6) can be infinitely adjusted from 0° to
45°.
1. Loosen the clamping screw (23) and the locking screw
for sanding table (7).
2. Now set the desired angle.
3. Tighten the clamping screw (23) and the locking
screw for sanding table (7) again.
