• Avoid awkward hand positions where a sudden slip
could cause your hand to touch the sanding belt or
disc.
• When sanding a large piece of material, provide an
additional support at table height.
• Never sand an unsupported workpiece. Secure the
workpiece with the table or the stop. Exceptions are
the sanding of curved workpieces on the outside of
the sanding disc.
• Always clear the table, fence or sanding belt of scraps
or other objects, before turning the product on.
• Do not perform any layout assembly or set-up work on
the table while the product is in operation.
• Switch the product off and pull the power plug from
the socket when fitting or removing accessories.
• Never leave the working area of the product while the
product is running, or as long as it has not come to an
absolute standstill.
• Always place the workpiece on the sanding table or
position it firmly against the sanding stop. Place
curved workpieces securely on the table when sand-
ing on the sanding wheel.
• Always ensure that the belt and disc sander are stable
and secured (e.g. fastened to a workbench).
• Before each use, check the sanding disc and sanding
belt for damage.
• Replace worn or damaged sanding discs and sanding
belts immediately.
• Always use the protective cover and the workpiece
support as required for the insert tools.
• Always use the electric tool with insert tools on both
spindles to limit the risk of contact with the rotating
spindle.
5.7
Residual risks
The product has been built according to state-of-the-
art and the recognised technical safety rules. Howev-
er, individual residual risks can arise during opera-
tion.
• Risk of injury for fingers and hands due to the rotating
sanding disc with improper guiding or positioning of
the tool to be sanded.
• Risk of injury from tools thrown away due to improper
holding or guiding.
• Health hazard due to electrical power, with the use of
improper electrical connection cables.
• Furthermore, despite all precautions having been met,
some non-obvious residual risks may still remain.
• Residual risks can be minimised if the "Safety Instruc-
tions" and the "Intended Use" together with the oper-
ating manual as a whole are observed.
WARNING
This power tool generates an electromagnetic field
during operation. This field can impair active or passive
medical implants under certain circumstances. In order
to prevent the risk of serious or deadly injuries, we rec-
ommend that persons with medical implants consult
with their physician and the manufacturer of the medical
implant prior to operating the power tool.
6
Technical data
AC motor
Rated input
Dimensions L x W x H
ø disc
RPM disc
Grinding belt size
Grinding belt speed
Angle positioning
Table size
Table angle positioning
Weight
Subject to technical changes!
WARNING
Noise can have serious effects on your health. If the
machine noise exceeds 85 dB, please wear suitable
hearing protection for you and persons in the vicinity.
The noise and vibration values have been determined in
accordance with EN 62841-1.
Sound pressure L
Uncertainty K
Sound pressure L
Uncertainty K
The total vibration emission values specified and the de-
vice emissions values specified have been measured in
accordance with a standardised test procedure and can
be used for comparison of one electric tool with another.
The total noise emission values specified and the total vi-
bration emission values specified can also be used for an
initial estimation of the load.
Note:
• The vibration values and noise emission values can
vary from the specified values during the actual use of
the electric tool, depending on the type and the man-
ner in which the electric tool is used, and in particular
the type of workpiece being processed.
• It is necessary to define safety measures to protect
the operator which are based on an estimate of vibra-
tion exposure during the actual operating conditions
(for this, all parts of the operating cycle have to be
considered, e.g. times during which the power tool is
switched off and times during which it is switched on
but runs in no-load mode).
7
Unpacking
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the trans-
port company that delivered the Product. Later claims
will not be recognised.
www.scheppach.com
410 x 380 x 295 mm
pA
pA
wA
wA
230 V∼/50 Hz
400 W
150 mm
rpm
2000 − 2980
915 x 100 mm
5.1 - 7.5 m/s
0° − 90°
230 x 152 mm
0° − 45°
approx. 14.5 kg
77.1 dB
3 dB
90.1 dB
3 dB
GB | 21
