If the nodes allocated to master 3 need to be operated on master 1, it is
possible to switch the whole of SIMOLINK ring 3 over to master 1 and
operate it in conjunction with ring 1 as a combined SIMOLINK ring
comprising 1.1 and 1.2.
Master 1
SIMOLINK-SWITCH SLS
SIMOLINK ring 1.1
(1)
Fig. 2-3
SIMOLINK ring 3 is operating on master 1
Operating Instructions
Master 2
SIMOLINK-SWITCH SLS
SIMOLINK ring 2
Description
Master 3
SIMOLINK ring 1.2
(3)
2-3
