8.4 Pump operation
Settings on pump
Carry out settings by turning and pressing the operating button. Turn the operating button to the left or
right to browse the menus or configure settings.
NOTICE
If there are no warning or error messages, the display on the electronic module will switch
off 2 minutes after the last time it was operated.
• If the operating button is pressed or turned again within 7 minutes, the previously exited
menu will appear. You can continue to configure settings.
• If the operating button is not pressed or turned for more than 7 minutes, any unconfirmed
settings will be lost. Pressing the button again opens the home screen on the display and the
pump can be operated from the main menu.
Initial settings menu
The settings menu will appear in the display during initial commissioning of the pump.
• Stratos MAXO/Stratos MAXO-D: The pump runs in the factory setting → Application: Radiator; Control
mode: Dynamic Adapt plus.
• Stratos MAXO-Z: The pump runs in the factory setting → Application: Domestic hot water circulation;
control mode: Temperature T-const.
If necessary, press the Context button
The pump runs in factory setting when the initial commissioning menu is open.
• The initial settings menu is exited when "Start with factory settings" is activated by pressing the operating
button. The display changes to the main menu. The pump continues to run in the factory setting.
• If venting has been started, other settings can be made in the meantime.
• In the "First settings" menu, settings that can be selected and adjusted include language, units, applica-
tions and night setback.
The chosen initial settings are confirmed by activating "Finish initial settings". The display changes to the
main menu.
NOTICE
Additional information regarding operation, control functions / additional control functions,
setting menu / setting assistant, saved configuration/ saved data, Wilo Net, device settings,
twin-head pump operation display, further settings on the pump, and firmware updates are
available in a separate user manual on the internet. See QR code at the beginning of these
installation and operating instructions.
9 Setting the control functions
9.1 Basic control functions
Depending on the application, basic control functions are available.
The control functions can be selected with the setting assistant:
• Differential pressure Δp-c
• Differential pressure ∆p-v
Installation and operating instructions • Wilo-Stratos MAXO/-D/-Z • Ed.01/2023-02
and go to the Language menu to change the language.
