Wear hearing protection.
Excessive noise can result in a loss of hearing.
Sound pressure level L
pA
Uncertainty K
pA
Sound power level L
WA
Uncertainty K
WA
The stipulated values are emission values and so do
not necessarily represent safe working site values. Al-
though there is a correlation between emission levels
and exposure levels, it is not possible to reliably deter-
mine whether additional precautionary measures will
be required or not based on this. Factors that could
influence the emissions level present at any given time
at the work station include the duration of exposure,
the nature of the working area, other noise sources
etc. e.g. the number of machines and neighbouring
processes.
The permitted workstation values can also vary from
country to country. However, this information should
enable the operator to better evaluate the hazards and
risks.
Limit the noise level to a minimum!
• Only use faultless devices.
• Maintain and clean the device at regular intervals.
• Adapt your working methods to the device.
• Do not overload the device.
• Have the device checked if necessary.
• Switch the device off if it is not in use.
Suitable saw blades
All industry-standard saw blades with a minimum
length of 133 mm with and without a pin may be used.
7. Before commissioning
7.1 Unpacking
• Open the packaging and carefully remove the de-
vice.
• Remove the packaging material, packaging and
transport safety devices (if applicable).
• Check that the delivery is complete.
• Check the device and accessory parts for transport
damage.
• If possible, keep the packaging until the expiry of the
warranty period.
WARNING
The device and the packaging are not children's
toys! Do not let children play with plastic bags,
films or small parts! There is a danger of choking
79.6 dB(A)
or suffocating!
3 dB
92.6 dB(A)
7.2 General notes
• Prior to commissioning, all covers and safety devic-
3 dB
es must be mounted correctly.
• It must be possible for the saw blade to run freely.
• In case of previously machined wood, be aware of
any foreign bodies, such as nails or screws, etc.
• Before pressing the on/off switch, make sure that the
saw blade is correctly fitted, and that moving parts
run smoothly.
• Before connecting the machine, make certain that
the data on the type plate matches with the mains
power data.
• Only connect the machine to a correctly installed
protective contact socket, with fuse protection of at
least 10 A.
7.3 Installing the scroll saw on a workbench
(fig. 5.1)
The tools/small parts required for the installation are
not supplied with the saw.
• Hexagon screw M6 (3x)
• Hexagon nut M6 (3x)
• Washer Ø 6.4 mm (6x)
• Drill template (fig. 5.2)
The length of the screws to be used vary depending on
the thickness of the tabletop.
WARNING
Danger of injury! Disconnect the mains plug on the
scroll saw before all assembly work.
1. Mount the scroll saw on a solid wooden work-
bench. This way, a high noise level due to vibra-
tions can be avoided.
2. Mark the drill holes using the drill template (see
fig. 5.2).
3. Drill the 3 holes (diameter 6 mm) into the work-
bench.
4. Screw the scroll saw onto the workbench with the
hexagonal bolt (E) through the assembly points
(fig. 3 pos. 19) in the following sequence (fig. 5.1):
D Hexagonal nut
C Washer
A Scroll saw
