Technical Data

Maximum angle
Measuring range
Measurement accuracy
Electrical connection
Degree of protection
Degree of pollution
Power supply
Height
Ambient humidity
Temperatures
Storage temperature
Environmental temperature
Operational temperature
Signal mA output
+/- 4°
0.1-15 m
+/- 5 mm
18-30 VDC
max
1.8 W 0.1 A
Note: Power is supplied via a 100-240 V plug-in power supply unit (24 V
supply voltage) or via the PLC (24 V DC voltage SELV)
Protection against contact and moisture in accordance with IP 66
(EN 60529) and NEMA-4X/indoor (NEMA 250) if powercable or 0/4-20mA
cable is connected properly.
2
Overvoltage category II
max. 2,000 m (ASL)
max. 95 %
-10 °C to +50 °C
-10 °C to +45 °C
Note: The sensor is not intended for outdoor use.
+1 °C to 45 °C
0/4-20 mA galvanically isolated, max. load 450 Ω.
Range adjustable via Bluetooth® with DULCONNEX Blue app.
5 EN
