COMPACT 1.4
EN
Take care not to invert polarities when connecting the unit. If this were to happen, the control plate will
not come on, the unit will not work.
Centrifugal
blower
Az
Blue
N
Black
R
Red
V
Green
B
White
A
Yellow
Na Orange
M
Brown
Compressor
electronic
module
All manuals and user guides at all-guides.com

IMPORTANT WARNING!

Electronic
module
Current cut-off
2 Compressor
Compressor
32

Electric wiring

Return
air sensor
Condenser fan
electronic
module
1 Compressor
®
