Electric Wiring; Important Warning - dirna Bergstrom TRP DYNAMIC Benutzerhandbuch

DYNAMIC
EN
Take care not to invert the polarities when connecting the equipment to the battery. If this happens, the plate
does not come on and the unit does not work.
Condenser fan
Az Blue
N Black
R Red
V Green
B White
A Yellow
Na Orange
M Brown

IMPORTANT WARNING!

Return
air sensor
Blower
Anti-freeze
sensor
Battery
12

Electric wiring

-
+
ºC
ºF
TEMP
Compressor
Electronic module
Compressor
®
