RSP3 installation and user's guide
www.renishaw.com
RSP3 straight stylus carrying capability
Probe/ stylus holder
RSP3-1 / RSH3-1
RSP3-2 / RSH3-2
RSP3-3 / RSH3-3
RSP3-4 / RSH3-4
RSP3-6 / RSH3-6c-500
RSP3-6 / RSH3-6c-600
RSP3-6 / RSH3-6-600
RSP3-6 / RSH3-6-700
RSP3-6 / RSH3-6-800
* Straight styli may be added to the RSH3-6c stylus holders.
Issued 10 2019
Effective stylus reach (by
using these stylus lengths)
20 mm - 50 mm
(20 mm - 50 mm)
44 mm - 99 mm
(20 mm - 75 mm)
114 mm - 194 mm
(20 mm - 100 mm)
214 mm - 394 mm
(20 mm - 200 mm)
348 mm (M2 star centre)*
448 mm (M2 star centre)*
456 mm (10 mm)
556 mm (10 mm)
656 mm (10 mm)
Maximum permissible stylus
length vs (mass)
20 mm (7 g)
30 mm (10 g)
40 mm (13 g)
50 mm (14 g)
20 mm (2.5 g)
40 mm (7.5 g)
50 mm (9.5 g)
75 mm (10.5 g)
20 mm (8 g)
50 mm (9 g)
75 mm (10 g)
100 mm (10 g)
20 mm (7.5 g)
100 mm (8.5 g)
150 mm (9 g)
200 mm (9 g)
n/a
n/a
10 mm (3.42 g)
10 mm (3.42 g)
10 mm (3.42 g)
Maximum operating stylus tip
deflection for above in any
orientation
0.5 mm
0.5 mm
0.5 mm
0.5 mm
0.5 mm
0.5 mm
0.5 mm
0.5 mm
0.5 mm
