Step 3: Secure the half shell to the bottom of the spotting scope using the locking screw.
The spotting scope and half shell can be used either hands-free or supported, for
example, on a backpack. The protective half shell allows both the focusing ring and
the magnification adjustment ring to be rotated by 360° when placed on a surface.

2.5 ADJUSTING THE TWIST-IN EYECUP

For use without glasses: unscrew the twist-in eyecup (counter-
clockwise) as far as it will go.
For use with glasses: screw in the twist-in eyecup (clockwise)
as far as it will go.
20
ATC/STC / EN ATC/STC / DE

2.6 ADJUSTING THE FOCUS

• For distant objects, turn the focusing adjustment ring to the
right (clockwise).
• Turning the adjustment ring to the left (counterclockwise)
allows you to observe objects from a close distance.
• For effortless observation, turn the focusing adjustment ring to the left (counterclock-
wise) until the image is slightly blurred. Then turn the adjustment ring to the right (clock-
wise) until the maximum image definition is reached.
Practical tip: use the focusing wheel on the spotting scope to continually set the focus.
This will help to stop your eyes feeling tired.
