m WARNING! This power tool generates an electro-
magnetic field during operation. This field can impair
active or passive medical implants under certain con-
ditions.
In order to prevent the risk of serious or deadly injuries,
we recommend that persons with medical implants
consult with their physician and the manufacturer of
the medical implant prior to operating the power tool.
6. Technical data
Voltage control
Protection category
Continuous output P
nenn
max. Power P max. (S2 5 min)
Rated battery voltage U
Rated current I
nenn
Frequency F
nenn
Drive motor type
Displacement
Motor speed
Max. power (engine)
Fuel
Tank contents
Engine oil type (recommended)
Oil volume (approx.)
Consumption at 2/3 load
Weight
Performance class
Power factor cos φ
Quality class
Max. temperature.
Max. altitude (above mean sea
level)
Starter
Spark plug
Technical changes reserved!
Operating mode S1 (continuous operation)
The machine may be operated continuously with the
specified power.
AVR
IP23M
(S1)
2500 W
2800 W
2 - 230 V~
nenn
11A
50 Hz
4-stroke 1
cylinder
air-cooled
212 cm
2000 min
4.3 kW
Unleaded petrol
15 l
10W30 / 15W40
0.6 l
1.05 l/h
44.7 kg
40
1000 m
Pull cable starter
F7RTC/F6RTC
www.scheppach.com
Operating mode S2 (short-term operation)
The machine may only be operated at maximum power
for a brief time. Then, the machine must be brought to
a standstill for a period of time so that it is not allowed
to heat up.
Noise
m Warning:Noise can have serious effects on your
health. If the machine noise exceeds 85 dB (A), please
wear suitable hearing protection.
Noise data
Sound power level L
Sound pressure level L
Uncertainty K
wa/pA
7.
Unpacking
• Open the packaging and carefully remove the de-
vice.
• Remove the packaging material, as well as the
packaging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the device and accessory parts for trans-
3
port damage.
-1
• If possible, keep the packaging until the expiry of
the warranty period.
m DANGER
The device and the packaging are not children's toys!
Do not let children play with plastic bags, films or small
parts! There is a danger of choking or suffocating!
8. Assembly / Before commissioning
m ATTENTION!
G1
Always make sure the device is fully assembled before
1
commissioning!
A
Your machine is not fully assembled.
C
°
Installing the transport wheel (fig. 3)
1.
Insert the guide (a) into the designated hole
2.
Feed the wheel axle (c) through the wheel (15).
3.
Now push the washer onto the wheel axle (C) and
slide the wheel axle (C) with the wheel (15) into
the guide (a).
4.
Secure the wheel axle each with a spring split
pin (D).
94.15 dB
WA
74.15 dB
pA
1.5 dB
GB | 23
