Rational iCombi Gas Umbauanleitung Seite 14

1 | MI_2156 Gas valve (hot air and steam) - dismantling and installation
Components included in delivery:
No.: Gas valve complete 061-101/201
1
2
3
4
5
6
General information
For the gas components installed in RATIONAL units, the documents of the
component manufacturer apply:
The documents of the component manufacturer, as well as the
information from RATIONAL, must be read before use.
14 / 156
(Art. no.: 87.01.838S):
Gas valve E01 LK1 061-101G/
201G-
(Art. no.: 70.01.675)
Gas blower seal 061-202 – (Art. no.: 70.01.148)
Gas valve seal E01 061-202G – (Art. no.: 70.01.193)
Compensation line cpl. 061-202G – (Art. no.: 70.01.268P)
Corrugated hose gas seal 061 -202 – (Art. no.: 70.01.622)
Screw M5x12 T25 f. gas valve E01 – (Art. no.: 10.01.902)
9
2
3
1
Gas valve complete 062G/102-202G
(Art. no.: 87.01.839S):
Gas valve E01 LK2 062G/102-202G–
(Art. no.: 70.01.676)
8
6
4
5
7
NOTICE
