3. Acquiring PANO Images
3. Direct the patient to smile and align the Canine Teeth Beam to the center of the
canines. Use the Canine Teeth Beam Lever (left side of the Control Panel) to
adjust the position of the beam.
Finishing Patient Positioning
1.
After checking the positions of the patient and the laser beam, tighten the Temple
Supports OPEN/CLOSE Wheel under the control panel to prevent the patient's
head from moving.
2.
Click the READY button on the Console Software. The X-ray exposure has not
started yet.
3.
Now go to 3.3 X-ray Exposure to start the exposure.
24
Make sure that the Temple Supports are in closed position
before clicking the READY button.
PaX-i Plus User Manual
