English
The number of fan motors varies depending on the unit year of manufacture
Units from year of manufacture 2004 – 2011 and year of manufacture 2011 – 2020
only have one fan motor.
1. Disconnect the dummy plug from the fan motor of the lower unit and connect the bus
cable from the condensation hood [
For units from year of manufacture 2004 -2011 and 2011 – 2020, there is only one
fan motor. For these units, disconnect the dummy plug on the fan motor and connect
the cable from the condensation hood.
2. Check the cable routing to the fan motor. If there is still any cable length remaining,
pull the bus cable straight and secure the rest of the cable in the electrical compart-
ment with a cable tie. Tighten the cable gland.
3. Fix the cable to the rear side of the unit with the self-adhesive cable holders supplied.
4. Mount the left side panel of the unit.
Connect the condensation hood with the units (see Connecting the condensation hood
with the unit).
70 / 188
NOTICE
Photo 24].
80.51.936_iCombiPro-iCombiClassic_UV-P-CD-Komp_IM_EU
5 | Installation iCombi
