D R I V E 6 0 0 0 O p e r a t i n g M a n u a l
5.3 Please check before installation
- Data on name plate matches with other documents such as drawings, parts list, etc.
- In case of gearmotor, check if power is up to the motor requirements
- Inspect the gearbox for possible damage.
- Provide the recommended lubricants according to the environment of the installation.

5.4 Before starting up

The anti-corrosive agent (Valvoline Tectyl 846/K19) used for transportation and storage on the
shaft-ends or hollow shafts, and on the central seats must be removed before start up. This anti-
corrosive agent can be removed using an alkaline detergent; under no circumstances is it to be
removed mechanically (abrasive etc.). The alkaline detergent must not come into contact with the
seals.
When handling lubricants and anti-corrosive agents please observe the respective safety instruc-
tions for people and environment according to DIN 52 900.
5.5 Installation
The drive should be installed so that it is easily accessible for any future lubrication or grease top-
up.
First establish a perfect level, using a non-distorting and vibration- absorbing base for the com-
plete mounting area, and align the drive before tightening the fastening screws. Check all fasten-
ing screws for correct torque after about 4 weeks. Dowl pins (e.g. DIN 6325 cylinder pins) are to
be used in addition to the base fastening with screws of property class 8.8 or greater if the drive
is being driven to the maximum output torque or maximum radial load.
Units to be installed outdoors or in very unfavourable ambient conditions, e.g. dirt, dust, spray
water or heat, should be protected by covers. Free air access to the housing surface must not be
impaired under these circumstances.
Oil level, drain plug and breathing filter must also be clear for access.
.
In case of electrochemical corrosion risk due to contact of different metals such as cast iron and
fine steel, plastic protection of 2 or 3 mm thick should go between gear and machine. Screws
should also be protected by plastic discs. In addition, protect the housing with earthing screws
fixed to the motor.
Special corrosive protected units are available for installation in wet conditions.
When re-painting the unit, please cover carefully the breather and the shaft seals. Remove any
covering after the painting has been finished.
D6000_GB_08_06 NO. 991009 Issue: 08/2006 page 20
