8 . L u b r i c a t i o n

8.1 Grease lubrication

Grease lubricated CYCLO DRIVES are filled with grease at the factory and are ready for use
without refilling. The grease being used must not be mixed with other types of grease. The stan-
dard types of grease ESSO Unirex N2 (for lifetime lubrication) and Shell Alvania R2 are suitable
for ambient temperatures of -10°C to + 50°C, whereby self-heating of the units up to a maximum
of +60°C can be achieved during constant operation. Please contact Sumitomo Drive
Technologies if considering use of standard grease outside this temperature range, as well as the
use of other lubricants.

8.1.1 Lifetime grease lubrication

All CYCLO Drive 6000 units type CN.. are grease lubricated for life and can be mounted in any
position required. The units are filled with ESSO Unirex N2 at the factory and do not require any
refilling. The life can be increased if the grease is replaced after 20,000 hours or 4 to 5 years.
Grease quantity for grease change [g]
Size 606 607
1 st stage 25 25
2 nd stage
Output 35 35
8.1.2 Grease lubrication
CYCLO DRIVE 6000 lubricated with Shell Alvania R2 must be topped up after 500 operating
hours, or after 2 months in operation at the latest. Further top up is recommended every 2 or 3
months, or after 2 years in operation at the latest.
Grease quantities for top up (g)
Size 613DA
1 st stage 25
2 nd stage 450
Output 300
Size 618DA
1. stage 100
2. stage 1100
Output 600
Grösse 623DA
1. stage 750
2. stage 4000
Output 1000
Regreasing intervals
Operating conditions
up to 10 hours/day
10 - 24 hours/day
Grease change intervals
Section
High speed & speed reducer section
Output
Refilling and changing lubricants
CYCLO DRIVE 6000 from size 613 and larger, two-stage designs, are grease lubricated and are
fitted with grease nipples for regular regreasing.
D6000_GB_08_06 NO. 991009
608 609 610 611
65 90 140 200
70 100 100 90
613DB 613DC 614DA
90 140 25
450 450 450
300 300 300
618DB 619DA 619DB
450 150 450
1100 1500 1500
600 700 700
623DB 624DA 624DB
1100 750 1100
4000 4500 4500
1000 1100 1100
Regreasing interval
every 3 - 6 months
every 500 - 1000 hours
Grease change intervals
every 2 - 3 years
every 3 - 5 years
612 606DA 607DA 609DA 610DA 612DA 612DB
330 25 25
25 25
120 35 35
614DB 614DC 616DA
90 140 90
450 450 750
300 300 300
620DA 620DB 621DA
150 450 450
1500 1500 2000
700 700 800
625DA 625DB 626DA
1000 1500 1500
6000 6000 8000
1200 1200 1300
regreasing intervals must be shortened
in the case of use in difficult conditions
Comments
regreasing intervals must be
shortened in the case of use in
difficult conditions
Issue: 08/2006
25 25 25 90
90 140 330 330
100 100 120 120
616DB 617DA 617DB
140 90 140
750 1000 1000
300 500 500
621DB 622DA 622DB
750 450 1000
2000 2500 2500
800 900 900
Comments
