D R I V E 6 0 0 0 O p e r a t i n g M a n u a l
1 . G e n e r a l i n f o r m a t i o n
Please observe the following warnings
E l e c t r i c a l h a z a r d
Misapplication of the machine may be dangerous, risk of severe or fatal injury.
I m m i n e n t d a n g e r
Misapplication of the machine may be dangerous and lead to severe injures.
D a n g e r o u s s i t u a t i o n
Risk of physical injury
D a m a g i n g s i t u a t i o n
Risk of machine damage.
H e l pf u l i n f o r m a t i o n
Disposal
Please observe legal /environmental regulations.
2 . S a f e t y a d v i c e
Do not attempt to install or operate the CYCLO DRIVE until all of these instructions on assem-
bly, operation, maintenance and inspection and hazards are read and thoroughly understood.
Please keep these instructions next to the unit in operation to check at any time when neces-
sary.
Transportation, assembly, lubrication, operation, maintenance and inspection should only be
done by qualified personnel, so as to avoid personal injury or damage to property.
Do not touch moving mechanical components and make sure these parts are clear of obstruc-
tions. Failure to follow these instructions may result in personal injury, unit failure or damage to
property.
Only operate the unit in the application it was intended. Misapplication may result in physical
injury or damage to machinery.
3 . Tr a n s p o r ta t i o n r e c o m m e n d a t i o n s
The units must be checked for any transportation damage immediately upon receipt. Any dam-
ages should be reported to the carrier without delay. If there is any evidence of damage which
may put at risk the function of the CYCLO DRIVE, do not install the unit.
Lifting harnesses of suitable and adequate size are to be used; these are to be hooked into the
eye bolts or laid round the flange connections. Eye bolts on the gearbox are dimensioned for
the weight of the unit, no additional loads are allowed.
Caution: do not use the central bores in the shaft ends for lifting the drive with hooked bolts,
etc. This could result in damage to the bearings.
D6000_GB_08_06 NO. 991009 Issue: 08/2006 page 18
