Assembly and installation
4.3

Electrical installation

Do not shorten or mechanically damage the connecting cable.
Once connected, calibrate the inductive conductivity and temperature sensor.
Tab. 2: Terminal assignment, Dulcometer Compact
Terminal Function
X1.1 Transmission coil, signal
X1.2 Transmission coil, signal, earth
X2.1 Receiver coil, signal
X2.2 Receiver coil, signal, earth
XE2.2 Earth
XE4.1 Pt100x
XE4 Pt100x
The descriptions of the terminals refer to the ProMinent measuring and control unit, type DCCa. The
information about the colours relates to the leads of the sensor's fixed data line.
Connect the data line to the terminals of your ProMinent measuring and control unit, type DCCa. In
doing so, refer to the relevant operating instructions
Connect the data line to the terminals of your measuring/control unit. Refer to the operating
instructions for your measuring/control unit
24
Sensor ICT5 lead colours
[bn] , brown
[wh] , white
[pk] , pink
Cable shield for X2.1, transparent
Complete cable shield, black
[gn] green
[ye] yellow
