Align the straight solvent union so that the sample medium flows through the sensor eye (5).
Align the guide lip (1) of the adhesive connector towards the T-piece in the flow direction.
Installing the sensor type ICT5 into polypropylene (PP) pipework
2. You can install the sensor directly into an optionally available PP T-piece (order number
1096349, not included in the scope of delivery). The PP T-piece already includes the sensor
adapter.
Assembling the sensor into the T-piece
3. Place the sensor (5) into the T-piece so that the groove (4) on the sensor shaft engages with
the guide lip of the sensor adapter.
4. Manually screw the union nut tightly onto the thread of the sensor adapter.
5. Check the leak-tightness.
4.2 Installation of sensor type
ICT 5-IMA
Installation place
The transducer of sensor type ICT 5-IMA is
fully integrated in the immersion pipe. The
immersion pipe can either be connected to a
storage tank or channel using the holes pro‐
vided or using pipe clamps (on site).
Select a suitable installation site for the repre‐
sentative sample measurement.
Assembly and installation
