2. Devices and functional description
Legend
Item Name
1 Heating circuit 1 return line
2 Heating circuit 1 supply line
3 Heating circuit 2 return line
4 Heating circuit 2 supply line
5 Boiler return line
6 Boiler supply line
Optional pump group for third heating
7
circuit
A Insulation - rear
B Insulation - front
C Ball valve with thermometer
D HE pump
E Distribution bar diverter valve
Thermowell for distribution bar supply
F
line sensor
G Distribution bar
H Servomotor
Thermowell for heating circuit supply line
J
sensor
RV Backflow preventer in supply line
#1) For heat generators with internal pump only
#2) See chapter 4.4
24
Reference
Unmixed circuit, e.g. for domestic water
heater
#1
if included
Standard / differential pressure arm #2
For 6-mm temperature sensor
Mixed circuit only
