1.

Description

1.1

Introduction

Emotron EMX-R is a series of speed controlled drive systems specially designed
for driving rotary heat exchangers. The drive system consist of a motor and its
associated control unit.
EMX-R completely replaces drive systems EMS-VVX 1, 2-4N, 2-4N/ET and
2-4EM as well as the drive systems EMS-VVX 15, 25 and 35. All mentioned
drive systems have completely been replaced by EMX-R.
The drive system Emotron EMX-R is based, like its predecessor, on the
SR-motors (SR=Switched Reluctance). These motors make it possible to drive
heat exchanger rotors up to 3.5 metres in diameter without gears.
10-F08 10-F08
Fig. 1 Emotron Motor and Control unit for rotary heat exchangers.
Emotron AB 01-3333-01r3
Heat exchanger rotor
Control unit
Motor
