Emotron EMX- R Betriebsanleitung Seite 20

L N
1
10-F05
Fig. 5 Location of terminals, etc.
No.
1 Supply terminal
2 Motor terminal
3 Priority potentiometer
4 Control signal terminal
5 DIP switch
6 Test switch
7 Alarm terminal
8 Operating indicator for Model S, two LEDS
Emotron AB 01-3333-01r3
1 2 3 4 5 6 31 32 33 34 35 36 37
2
3 4
8
ON
ON
1 2 3 4 5 6 7 8
41 42 43
5 6
Designation
Mounting/connection
I U
J1
51 52 53 54 55 56 57 58
Extra circuit board in
the Model E with LED-
display,
E-terminals 51-58
and jumper J1
7
15
