4.2 Choice for sizes of drive system and belt
pulley
Table 9 Choice of size for drive system and belt pulley
Rotor
diameter
[mm]
700 15
700 15
900 15
900 15
1100 15
1100 15
1300 15
1300 15
1500 15
1700 25
1900 25
2100 25
2300 25
2500 25
2700 35
3100 35
3500 35
NOTE: Higher rotor speeds than those given in the table above increase the
loading and a larger drive system may be necessary. Tight rotor seals may
also require the use of a larger size. Rotors that have a high capacity to
absorb humidity, such as dehumidification rotors in desiccant cooling
system requires a larger drive system, see separate documentation.
Emotron AB 01-3333-01r3
Belt pulley
EMX-R
diameter
model
[mm]
63
30
63
40
63
50
71
63
71
80
80
100
100
100
118
140
140
Maximum speed
of revolution
[%]
60
100
60
100
80
100
80
100
100
100
100
100
100
100
100
100
100
Technical data
Rotor speed
[rpm]
13.5
10.7
10.5
11.1
11.5
11.4
10.9
12.1
11.8
11.8
10.5
11.9
10.9
10.0
10.9
11.3
10.0
29
