Spacing disc
Alternative load application
Fig. 4.1 Load application and installation
Important
Load must not be applied to the side where the cable connection is located, as this would
cause a force shunt.
PW15B
MECHANICAL INSTALLATION
=
=
Load application
Load application
=
Direction of loading center of platform
=
=
Spacing disc
Direction of loading center of platform
=
Covering agent for
ATEX versions
(see dimensions)
Connection cable
Mounting
Assembly bores
