Setting the DMX Start Address:
Mode:
D
001 - 512
Controlling:
After having addressed the LED PAR-64 W/A 36x1W, you may now start operating it via your lighting
controller.
Note:
It's necessary to insert the XLR termination plug with 120
proper transmission on the DMX data link.
Choosing a DMX Channel Mode with 2 or 4 Channal Occupation
The device has 2 DMX-modes. The Control Board allows you to assign the DMX-Mode.
Setting DMX Mode
Press the MODE button until the display shows 2-CH or 4-CH. You can now set the channel mode via the
UP or DOWN buttons.
Mode:
Function:
2-CH
2 Channel Occupation
4-CH
4 Channel Occupation
Master/Slave operation
The master/slave operation enables that several devices can be synchronized and controlled by one master
device.
On the rear panel of the device you can find an XLR jack and an XLR plug, which can be used for
connecting several devices.
Choose the device which is to control the effects. This device then works as master device and controls all
other slave devices, which are to be connected to the master device via a DMX-cable. Connect the OUT jack
with the IN plug of the next device.
MASTER device:
SLAVE device(s):
Do not connect a DMX controller to the master device in this operating mode.
DMX-protocol
4 Channel Mode
Channel:
Value:
1
000 – 255
Channel:
Value:
2
000 – 255
Channel:
Value:
3
000 – 255
Channel:
Value:
000 – 015
4
016 – 255
Value:
Use any one of the stand-alone modes for the master unit.
Press the MODE button until the display shows 2-CH or 4-CH, then use the UP or
DOWN button to set the DMX address to d001.
Function:
Dimmer (0 – 100%)
Function:
Warm white (0 – 100%)
Function:
Cool white (0 – 100%)
Function:
No function
Strobe (increasing)
in the last lighting in the link in order to ensure
20/21
00051972.DOC, Version 1.1
