Internal Programs

Press the MODE button to select the internal program mode. When the display shows P, you can select the
desired internal program via the UP or DOWN buttons (see following graphic).
Mode:
P

DMX MODE

The Control Board allows you to assign the DMX fixture address, which is defined as the first channel from
which the AC-300 DMX LED/RGB Base will respond to the controller.

Addressing

Press the MODE button until the display shows D. You can now set the desired address via the UP or
DOWN buttons.
Setting the DMX Start Address:
Mode:
D
001 - 512
Controlling:
After having addressed the AC-300 DMX LED/RGB Base, you may now start operating it via your lighting
controller.
Note:
It’s necessary to insert the XLR termination plug with 120
proper transmission on the DMX data link.

Choosing a DMX Channel Mode with 3 or 5 Channal Occupation

The device has 2 DMX-modes. The Control Board allows you to assign the DMX-Mode.
Setting DMX Mode
After setting the desired address via the UP or DOWN buttons, press the MODE button again and the
display shows 5ch.
In case you would rather select the 3-channel mode, press the DOWN button in order to choose the 3ch
setting.
Mode:
5ch (default setting)
Value:
P1
P2
P3
P4
Value:
Value:
3ch
Function:
Endless loop in 7 colors,
change every 3 seconds
Endless loop in 7 colors,
fade every 8 seconds
Endless loop in 3 colors,
change every 3 seconds
Endless loop in 3 colors,
fade every 8 seconds
in the last lighting in the link in order to ensure
Ω
18/20 00062123.DOC, Version 1.1
