With the RS 232/422/485 connected, a bi-directional communication
is established by selecting HOST. Data are sent to an external
computer every time the external computer asks for the values. The
available data are listed in the read mode in the serial protocol table.
With the serial module installed, the data can also be read in the FRONT or
NOTE
REMOTE mode.
If PRINT is selected and a printer is connected on RS 232/422 line, an
unidirectional communication is established and every minute the
data are sent to the printer, even if the pump is not running.
The set of data available are:
Turbo-V 1000 ICE Controller User Manual / 87-900-905-01 (M)
Pump speed KRPM
Pump temperature
Pump current A
Pump power W
S1 condition
S2 condition
Confirm the selection by pressing the PUMP CURRENT push-
button.
In this way you enter into an operating phase named "Monitor
Relay Programming" described later.
•Enter the value by pressing the PUMP CURRENT push-button.
