Monitor Relay Programming

H
S
where: XXKRPM = is the switch point of relay S1 at the preset
turbopump speed, adjustable from 00 to 38 KRPM. The speed
threshold will condition the S1 operation (see the following cycle
diagram] and it is factory-set to 36 KRPM. The speed threshold will
condition the S2 operation (see the following cycle diagram] and it is
factory-set to 24 KRPM.
Figure 34
Turbo-V 1000 ICE Controller User Manual / 87-900-905-01 (M)
The display shows:
. S .
E T T I
T H R E S
N G ; X
Technical Information
Use
H O L D
X K R P M
257/268
17
