When there are two temperature sensors
X
T
Figure 21
where:
Turbo-V 1000 ICE Controller User Manual / 87-900-905-01 (M)
X K R
1 = X. X.
I = is the DC current drawn by the pump range (0.00 to 10.0
Ampere)
P= is the DC power drawn by the pump (range 0 to 999 Watt)
KRPM = is the theoretical rotational speed of the pump as a
function of the controller output frequency (range 3 to 38 KRPM)
T1 = is the temperature of the outer ring of the upper bearing
(range 00 to 99 °C)
T2 = is the temperature of the outer ring of the lower bearing
(range 00 to 99 °C)
P M P
° C T
Technical Information
Use
= X X X W
2 = X X.°
