Electrical connection cables must comply with the ap-
plicable VDE and DIN provisions. Only use connection
cables with the marking „H05VV-F".
The printing of the type designation on the connection
cable is mandatory.
AC motor
• The mains voltage must be 230 V~
• Extension cables up to 25 m long must have a
cross-section of 1.5 mm2.
Connections and repairs of electrical equipment
may only be carried out by an electrician.
Please provide the following information in the event of
any enquiries:
• Type of current for the motor
• Machine data - type plate
• Machine data - type plate

14. Troubleshooting

Fault Possible cause
Motor does not work Motor, cable or plug defective, fuses burnt
The motor starts up Voltage too low, coils damaged, capacitor
slowly and does not burnt
reach operating speed.
Motor makes excessive Coils damaged, motor defective
noise
The motor does not Circuits in the network are overloaded (lamps,
reach its full power. other motors, etc.)
Motor overheats easily. Overloading of the motor, insufficient cooling
of the motor
Reduced cutting power Saw blade too small (ground too much)
when sawing
Saw cut is rough or Saw blade dull, tooth shape not appropriate for
wavy the material thickness
Workpiece pulls away Excessive cutting pressure and/or saw blade
and/or splinters not suitable for use
28 GB/IE

13. Disposal and recycling

The equipment is supplied in packaging to prevent it
from being damaged in transit. The raw materials in
this packaging can be reused or recycled. Never place
batteries in your household refuse, in fire or in water.
Batteries should be collected, recycled or disposed of
by environment-friendly means. The equipment and
its accessories are made of various types of material,
such as metal and plastic. Defective components must
be disposed of as special waste. Ask your dealer or
your local council.
Remedy
Arrange for inspection of the machine by a
specialist. Never repair the motor yourself. Danger!
Check fuses and replace as necessary
Contact the utility provider to check the voltage.
Arrange for inspection of the motor by a specialist.
Arrange for replacement of the capacitor by a
specialist
Arrange for inspection of the motor by a specialist
Do not use any other equipment or motors on the
same circuit
Avoid overloading the motor while cutting, remove
dust from the motor in order to ensure optimal
cooling of the motor
Readjust end stop of the saw unit
Resharpen saw blade and/or use suitable saw blade
Insert suitable saw blade
