EX-1170HMVS
3. Layout, Connections & Jumper Settings
3.2 Connections
USB 2.0 B-Port:
3.3 Jumper Einstellungen
The EX-1170HMVS will be delivered with the setting USB-Bus-Power.
ity to cut the power at the data line.
sides. Then you must set the jumper JP1 from ENA (Enable) to DIS (Disable). See the following
picture.
Attention! Only with connected Power Supply! Furthermore, you have the option to leave power
on the DFP (Downstream Facing Ports) only when the hub is connected to the host PC and the
host PC is switched on. For this you have to set the jumper JP2 to "HOST". If JP2 is set to "ON",
there is continuous power on the downstream ports. See the following picture.
JP1
© Copyright 2023 by EXSYS Vertriebs GmbH. All Rights Reserved
USB 2.0 B-Port
Pin
Signal
1
VCC
2
DATA-
For this you open the case with the four screws on both
JP2
DIS
ENA
HOST
ON
11
Pin
Signal
3
DATA+
4
GND
But you have the possibil-
